AOY18TNAL
AOG18TNAL
Part No.
AOY18TNAL
AOG18TNAL
– 32 –
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
OUTDOOR UNIT
AOY18TNAL
AOG18TNAL
620 Inlet Pipe (Cond.) Assy 9371299051
653-1 Cup Screw 9385089020
734 Cabinet Top Plate, Painted 9359799023
754 Terminal Gasket Washer 9351053017
815 Terminal-8P 9358660119
823-2 Fuse Holder 0500063024
823-4 Fuse 0600222529
829 Joint Pipe (Strainer) 9372071014
867 Accumulator Hold. Rubber 9354022027
989-1 Cord Clamp-A 9359822011
34 Capacitor (Fan Motor) 9357965024
37 Running Capacitor 9703107122
38 Capacitor Clamp Metal 9351770013
39 Propeller Fan 9359837015
41 Fan Motor Assy-OUT 9600832011
45-3 Motor Bracket-A 9369627002
45-4 Motor Bracket-B 9371439013
45-5 Motor Bracket-C 9369629006
45-6 Motor Bracket-D 9369630002
46 Compressor Assy 9371975016
51 Special Nut M5 9300301015
55 Special Nut M8 (For Comp.) 9355091008
989-2 Cord Clamp-B 9359823018
2 Fan Cover (Guard) 9359808015
4 Emblem-Rear "FUJITSU" 9359836018
4 Emblem-Rear "GENERAL" 313791088308
5 Cabinet-A, Painted 9359797043
7 Connector Cover (Panel, Top) 9358011010
8 Wire Assy (Shield)-D 9371562025
9 Cabinet-B, Painted 9361323025
12 Base Assy, Painted 9359813019
13 3-Way Valve (1/2) (R407C) 9362378000
14 2-Way Valve (1/4) (R407C) 9362380003
16 Condenser Assy 9371970011
17 U pipe-Y 313728127102
18-1 Suction Pipe-B 9371297040
18-2 Suction Pipe-C 9371297057
18-3 Suction Pipe-D 9371297064
18-4 Suction Pipe-E 9371297071
20 Discharge Pipe Assy 9371590028
26 Compressor Cover-A 9365154007
29 Separate Wall 9359805014
32 Control Box Assy-A 9361409026
64 Cabinet-Left, Painted 9359840046
69-3 Bolt, Hex. Socket 301210060360
84 Valve Cover 9361325012
85 Valve Fixing Plate 9361324015
107 Rubber Mount (For Comp.) 9351049010
109 Terminal Cover (For Comp.) 9371511016
117-3 Hexagon Nut 301721180114
(Spring Lock Washer)
187 Clamp No. 1219 313361271706
218-3 Power Relay 9900074012
272 Strainer 9369287008
328 Compressor Plate Assy 9362273060
333 Accumulator 9364284002
335 Condensing Pipe 9371860022
343 Solenoid Coil 9704061010
344 4-Way Valve 9307556012
412 Terminal Gasket (For Comp.) 9371512013
477 Bellmouth 9359809012
519 Capillary Assy 9371287072
527 Protection net (Condenser Net) 9359845010
Ref.
No.
Description
Ord.
Q'ty
Part No.
Ref.
No.
Description
Ord.
Q'ty
2003.05.14
To Next Page
