Fujitsu ASY50-KM Design & Technical Manual


Compact cassette type
Model: AUXG07KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
-5.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
0.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
5.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
10.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
15.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
20.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
25.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
30.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
35.0 1.96 1.32 2.22 1.51 2.34 1.74 2.50 1.95 2.67 2.13 2.76 2.44
40.0 1.45 0.72 1.64 0.83 1.73 0.95 1.85 1.07 1.98 1.17 2.04 1.34
46.0 0.94 0.30 1.06 0.35 1.12 0.40 1.20 0.45 1.28 0.49 1.32 0.56
Model: AUXG09KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
-5.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
0.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
5.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
10.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
15.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
20.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
25.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
30.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
35.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
40.0 1.86 0.92 2.10 1.04 2.21 1.20 2.37 1.35 2.53 1.48 2.61 1.69
46.0 1.20 0.38 1.36 0.44 1.43 0.51 1.54 0.57 1.64 0.62 1.69 0.71
Model: AUXG12KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
-5.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
0.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
5.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
10.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
15.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
20.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
25.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
30.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
35.0 3.37 2.22 3.81 2.53 4.02 2.91 4.30 3.27 4.60 3.57 4.74 4.10
40.0 2.49 1.21 2.82 1.38 2.97 1.59 3.18 1.79 3.40 1.96 3.51 2.24
46.0 1.62 0.51 1.83 0.58 1.93 0.67 2.06 0.75 2.21 0.82 2.27 0.94
Model: AUXG14KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
-5.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
0.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
5.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
10.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
15.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
20.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
25.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
30.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
35.0 3.92 2.44 4.43 2.78 4.67 3.20 5.00 3.60 5.35 3.94 5.51 4.51
40.0 2.90 1.34 3.28 1.52 3.46 1.75 3.70 1.97 3.96 2.16 4.08 2.47
46.0 1.88 0.56 2.13 0.64 2.24 0.74 2.40 0.83 2.57 0.91 2.64 1.04
- 488 -
6-2. Cooling capacity
6. Capacity table
OUTDOOR UNIT AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5
