Fujitsu ASY50-KM Design & Technical Manual

Model: AUXG18KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 4.85 2.94 5.48 3.35 5.78 3.86 6.19 4.33 6.62 4.74 6.82 5.43
-5.0 4.85 2.94 5.48 3.35 5.78 3.86 6.19 4.33 6.62 4.74 6.82 5.43
0.0 4.85 2.94 5.48 3.35 5.78 3.86 6.19 4.33 6.62 4.74 6.82 5.43
5.0 4.85 2.94 5.48 3.35 5.78 3.86 6.19 4.33 6.62 4.74 6.82 5.43
10.0 4.85 2.94 5.48 3.35 5.78 3.86 6.19 4.33 6.62 4.74 6.82 5.43
15.0 4.85 2.94 5.48 3.35 5.78 3.86 6.19 4.33 6.62 4.74 6.82 5.43
20.0 4.85 2.94 5.48 3.35 5.78 3.86 6.19 4.33 6.62 4.74 6.82 5.43
25.0 4.85 2.94 5.48 3.35 5.78 3.86 6.19 4.33 6.62 4.74 6.82 5.43
30.0 4.85 2.94 5.48 3.35 5.78 3.86 6.19 4.33 6.62 4.74 6.82 5.43
35.0 4.85 2.94 5.48 3.35 5.78 3.86 6.19 4.33 6.62 4.74 6.82 5.43
40.0 3.59 1.61 4.06 1.83 4.28 2.11 4.58 2.37 4.90 2.60 5.05 2.97
46.0 2.33 0.68 2.63 0.77 2.78 0.89 2.97 1.00 3.18 1.09 3.27 1.25
Model: AUXG22KVLA
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 6.12 3.70 6.91 4.22 7.29 4.86 7.80 5.46 8.34 5.97 8.60 6.84
-5.0 6.12 3.70 6.91 4.22 7.29 4.86 7.80 5.46 8.34 5.97 8.60 6.84
0.0 6.12 3.70 6.91 4.22 7.29 4.86 7.80 5.46 8.34 5.97 8.60 6.84
5.0 6.12 3.70 6.91 4.22 7.29 4.86 7.80 5.46 8.34 5.97 8.60 6.84
10.0 6.12 3.70 6.91 4.22 7.29 4.86 7.80 5.46 8.34 5.97 8.60 6.84
15.0 6.12 3.70 6.91 4.22 7.29 4.86 7.80 5.46 8.34 5.97 8.60 6.84
20.0 6.12 3.70 6.91 4.22 7.29 4.86 7.80 5.46 8.34 5.97 8.60 6.84
25.0 6.12 3.70 6.91 4.22 7.29 4.86 7.80 5.46 8.34 5.97 8.60 6.84
30.0 6.12 3.70 6.91 4.22 7.29 4.86 7.80 5.46 8.34 5.97 8.60 6.84
35.0 6.12 3.70 6.91 4.22 7.29 4.86 7.80 5.46 8.34 5.97 8.60 6.84
40.0 4.53 2.03 5.11 2.31 5.39 2.66 5.77 2.99 6.17 3.27 6.36 3.75
46.0 2.94 0.85 3.32 0.97 3.50 1.12 3.74 1.26 4.00 1.38 4.13 1.58
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
- 489 -
6-2. Cooling capacity
6. Capacity table
OUTDOOR UNIT AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5
