Fujitsu ASY50-KM Design & Technical Manual

Model: ARXG18KSLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 4.85 3.02 5.48 3.45 5.78 3.97 6.19 4.46 6.62 4.87 6.82 5.58
-5.0 4.85 3.02 5.48 3.45 5.78 3.97 6.19 4.46 6.62 4.87 6.82 5.58
0.0 4.85 3.02 5.48 3.45 5.78 3.97 6.19 4.46 6.62 4.87 6.82 5.58
5.0 4.85 3.02 5.48 3.45 5.78 3.97 6.19 4.46 6.62 4.87 6.82 5.58
10.0 4.85 3.02 5.48 3.45 5.78 3.97 6.19 4.46 6.62 4.87 6.82 5.58
15.0 4.85 3.02 5.48 3.45 5.78 3.97 6.19 4.46 6.62 4.87 6.82 5.58
20.0 4.85 3.02 5.48 3.45 5.78 3.97 6.19 4.46 6.62 4.87 6.82 5.58
25.0 4.85 3.02 5.48 3.45 5.78 3.97 6.19 4.46 6.62 4.87 6.82 5.58
30.0 4.85 3.02 5.48 3.45 5.78 3.97 6.19 4.46 6.62 4.87 6.82 5.58
35.0 4.85 3.02 5.48 3.45 5.78 3.97 6.19 4.46 6.62 4.87 6.82 5.58
40.0 3.59 1.66 4.06 1.89 4.28 2.17 4.58 2.44 4.90 2.67 5.05 3.06
46.0 2.33 0.70 2.63 0.79 2.78 0.91 2.97 1.03 3.18 1.12 3.27 1.29
NOTES:
• TC: Total Capacity (kW), SHC: Sensible Heat Capacity (kW)
• Values mentioned in the table are based on the following conditions:
– Pipe length: 5 m, Height difference: 0 m [Outdoor unit—Indoor unit]
- 491 -
6-2. Cooling capacity
6. Capacity table
OUTDOOR UNIT AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5
