Fujitsu ASY50-KM Design & Technical Manual


Slim duct type
Model: ARXG07KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
-5.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
0.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
5.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
10.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
15.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
20.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
25.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
30.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
35.0 1.96 1.36 2.22 1.55 2.34 1.78 2.50 2.00 2.67 2.19 2.76 2.51
40.0 1.45 0.74 1.64 0.85 1.73 0.97 1.85 1.10 1.98 1.20 2.04 1.37
46.0 0.94 0.31 1.06 0.36 1.12 0.41 1.20 0.46 1.28 0.50 1.32 0.58
Model: ARXG09KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
-5.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
0.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
5.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
10.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
15.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
20.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
25.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
30.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
35.0 2.51 1.67 2.84 1.90 2.99 2.19 3.20 2.46 3.42 2.69 3.53 3.09
40.0 1.86 0.92 2.10 1.04 2.21 1.20 2.37 1.35 2.53 1.48 2.61 1.69
46.0 1.20 0.38 1.36 0.44 1.43 0.51 1.54 0.57 1.64 0.62 1.69 0.71
Model: ARXG12KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
-5.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
0.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
5.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
10.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
15.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
20.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
25.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
30.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
35.0 3.37 2.27 3.81 2.59 4.02 2.99 4.30 3.35 4.60 3.67 4.74 4.20
40.0 2.49 1.25 2.82 1.42 2.97 1.63 3.18 1.84 3.40 2.01 3.51 2.30
46.0 1.62 0.52 1.83 0.60 1.93 0.69 2.06 0.77 2.21 0.85 2.27 0.97
Model: ARXG14KLLAP
Outdoor temperature
Indoor temperature (°CDB / °CWB)
18.0 / 12.0 21.0 / 15.0 23.0 / 16.0 27.0 / 19.0 29.0 / 21.0 32.0 / 23.0
(°CDB) TC SHC TC SHC TC SHC TC SHC TC SHC TC SHC
-10.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
-5.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
0.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
5.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
10.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
15.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
20.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
25.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
30.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
35.0 3.92 2.51 4.43 2.86 4.67 3.29 5.00 3.70 5.35 4.05 5.51 4.64
40.0 2.90 1.37 3.28 1.57 3.46 1.80 3.70 2.03 3.96 2.22 4.08 2.54
46.0 1.88 0.58 2.13 0.66 2.24 0.76 2.40 0.85 2.57 0.93 2.64 1.07
- 492 -
6-2. Cooling capacity
6. Capacity table
OUTDOOR UNIT AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5
