Fujitsu ASY50-KM Design & Technical Manual

Indoor unit connecting
capacity
Outdoor temperature
Indoor temperature
16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB
kBtu/h °CDB °CWB TC IP TC IP TC IP TC IP TC IP
37
-15.0 -16.0 7.8 2.88 7.6 2.94 7.4 3.00 7.2 3.06 7.0 3.12
-10.0 -11.0 9.1 3.25 8.9 3.32 8.7 3.39 8.5 3.46 8.2 3.53
-5.0 -7.0 9.5 2.93 9.3 2.99 9.1 3.05 8.8 3.11 8.6 3.17
0.0 -2.0 10.9 3.13 10.7 3.19 10.4 3.26 10.2 3.32 9.9 3.39
5.0 3.0 12.6 3.29 12.3 3.36 12.0 3.42 11.7 3.49 11.4 3.56
7.0 6.0 12.6 3.13 12.3 3.20 12.0 3.26 11.7 3.33 11.4 3.39
10.0 8.0 12.6 2.90 12.3 2.96 12.0 3.02 11.7 3.08 11.4 3.14
15.0 10.0 12.6 2.72 12.3 2.78 12.0 2.84 11.7 2.89 11.4 2.95
20.0 15.0 12.6 2.36 12.3 2.41 12.0 2.46 11.7 2.51 11.4 2.56
24.0 18.0 12.6 2.00 12.3 2.04 12.0 2.08 11.7 2.12 11.4 2.16
36
-15.0 -16.0 7.8 2.88 7.6 2.94 7.4 3.00 7.2 3.06 7.0 3.12
-10.0 -11.0 9.1 3.25 8.9 3.32 8.7 3.39 8.5 3.46 8.2 3.53
-5.0 -7.0 9.5 2.93 9.3 2.99 9.1 3.05 8.8 3.11 8.6 3.17
0.0 -2.0 10.9 3.13 10.7 3.19 10.4 3.26 10.2 3.32 9.9 3.39
5.0 3.0 12.6 3.29 12.3 3.36 12.0 3.42 11.7 3.49 11.4 3.56
7.0 6.0 12.6 3.13 12.3 3.20 12.0 3.26 11.7 3.33 11.4 3.39
10.0 8.0 12.6 2.90 12.3 2.96 12.0 3.02 11.7 3.08 11.4 3.14
15.0 10.0 12.6 2.72 12.3 2.78 12.0 2.84 11.7 2.89 11.4 2.95
20.0 15.0 12.6 2.36 12.3 2.41 12.0 2.46 11.7 2.51 11.4 2.56
24.0 18.0 12.6 2.00 12.3 2.04 12.0 2.08 11.7 2.12 11.4 2.16
35
-15.0 -16.0 7.8 2.88 7.6 2.94 7.4 3.00 7.2 3.06 7.0 3.12
-10.0 -11.0 9.1 3.25 8.9 3.32 8.7 3.39 8.5 3.46 8.2 3.53
-5.0 -7.0 9.5 2.93 9.3 2.99 9.1 3.05 8.8 3.11 8.6 3.17
0.0 -2.0 10.9 3.13 10.7 3.19 10.4 3.26 10.2 3.32 9.9 3.39
5.0 3.0 12.6 3.29 12.3 3.36 12.0 3.42 11.7 3.49 11.4 3.56
7.0 6.0 12.6 3.13 12.3 3.20 12.0 3.26 11.7 3.33 11.4 3.39
10.0 8.0 12.6 2.90 12.3 2.96 12.0 3.02 11.7 3.08 11.4 3.14
15.0 10.0 12.6 2.72 12.3 2.78 12.0 2.84 11.7 2.89 11.4 2.95
20.0 15.0 12.6 2.36 12.3 2.41 12.0 2.46 11.7 2.51 11.4 2.56
24.0 18.0 12.6 2.00 12.3 2.04 12.0 2.08 11.7 2.12 11.4 2.16
34
-15.0 -16.0 7.8 2.82 7.6 2.88 7.4 2.94 7.2 3.00 7.0 3.06
-10.0 -11.0 9.1 3.19 8.9 3.26 8.7 3.32 8.5 3.39 8.2 3.46
-5.0 -7.0 9.5 2.87 9.3 2.93 9.1 2.99 8.8 3.05 8.6 3.11
0.0 -2.0 10.9 3.07 10.7 3.13 10.4 3.19 10.2 3.26 9.9 3.32
5.0 3.0 12.6 3.22 12.3 3.29 12.0 3.36 11.7 3.43 11.4 3.49
7.0 6.0 12.6 3.07 12.3 3.14 12.0 3.20 11.7 3.26 11.4 3.33
10.0 8.0 12.6 2.85 12.3 2.91 12.0 2.97 11.7 3.02 11.4 3.08
15.0 10.0 12.6 2.67 12.3 2.73 12.0 2.78 11.7 2.84 11.4 2.89
20.0 15.0 12.6 2.32 12.3 2.36 12.0 2.41 11.7 2.46 11.4 2.51
24.0 18.0 12.6 1.96 12.3 2.00 12.0 2.04 11.7 2.08 11.4 2.12
33
-15.0 -16.0 7.8 2.82 7.6 2.88 7.4 2.94 7.2 3.00 7.0 3.06
-10.0 -11.0 9.1 3.19 8.9 3.26 8.7 3.32 8.5 3.39 8.2 3.46
-5.0 -7.0 9.5 2.87 9.3 2.93 9.1 2.99 8.8 3.05 8.6 3.11
0.0 -2.0 10.9 3.07 10.7 3.13 10.4 3.19 10.2 3.26 9.9 3.32
5.0 3.0 12.6 3.22 12.3 3.29 12.0 3.36 11.7 3.43 11.4 3.49
7.0 6.0 12.6 3.07 12.3 3.14 12.0 3.20 11.7 3.26 11.4 3.33
10.0 8.0 12.6 2.85 12.3 2.91 12.0 2.97 11.7 3.02 11.4 3.08
15.0 10.0 12.6 2.67 12.3 2.73 12.0 2.78 11.7 2.84 11.4 2.89
20.0 15.0 12.6 2.32 12.3 2.36 12.0 2.41 11.7 2.46 11.4 2.51
24.0 18.0 12.6 1.96 12.3 2.00 12.0 2.04 11.7 2.08 11.4 2.12
32
-15.0 -16.0 7.8 2.82 7.6 2.88 7.4 2.94 7.2 3.00 7.0 3.06
-10.0 -11.0 9.1 3.19 8.9 3.26 8.7 3.32 8.5 3.39 8.2 3.46
-5.0 -7.0 9.5 2.87 9.3 2.93 9.1 2.99 8.8 3.05 8.6 3.11
0.0 -2.0 10.9 3.07 10.7 3.13 10.4 3.19 10.2 3.26 9.9 3.32
5.0 3.0 12.6 3.22 12.3 3.29 12.0 3.36 11.7 3.43 11.4 3.49
7.0 6.0 12.6 3.07 12.3 3.14 12.0 3.20 11.7 3.26 11.4 3.33
10.0 8.0 12.6 2.85 12.3 2.91 12.0 2.97 11.7 3.02 11.4 3.08
15.0 10.0 12.6 2.67 12.3 2.73 12.0 2.78 11.7 2.84 11.4 2.89
20.0 15.0 12.6 2.32 12.3 2.36 12.0 2.41 11.7 2.46 11.4 2.51
24.0 18.0 12.6 1.96 12.3 2.00 12.0 2.04 11.7 2.08 11.4 2.12
31
-15.0 -16.0 7.8 2.82 7.6 2.88 7.4 2.94 7.2 3.00 7.0 3.06
-10.0 -11.0 9.1 3.19 8.9 3.26 8.7 3.32 8.5 3.39 8.2 3.46
-5.0 -7.0 9.5 2.87 9.3 2.93 9.1 2.99 8.8 3.05 8.6 3.11
0.0 -2.0 10.9 3.07 10.7 3.13 10.4 3.19 10.2 3.26 9.9 3.32
5.0 3.0 12.6 3.22 12.3 3.29 12.0 3.36 11.7 3.43 11.4 3.49
7.0 6.0 12.6 3.07 12.3 3.14 12.0 3.20 11.7 3.26 11.4 3.33
10.0 8.0 12.6 2.85 12.3 2.91 12.0 2.97 11.7 3.02 11.4 3.08
15.0 10.0 12.6 2.67 12.3 2.73 12.0 2.78 11.7 2.84 11.4 2.89
20.0 15.0 12.6 2.32 12.3 2.36 12.0 2.41 11.7 2.46 11.4 2.51
24.0 18.0 12.6 1.96 12.3 2.00 12.0 2.04 11.7 2.08 11.4 2.12
30
-15.0 -16.0 7.8 2.82 7.6 2.88 7.4 2.94 7.2 3.00 7.0 3.06
-10.0 -11.0 9.1 3.19 8.9 3.26 8.7 3.32 8.5 3.39 8.2 3.46
-5.0 -7.0 9.5 2.87 9.3 2.93 9.1 2.99 8.8 3.05 8.6 3.11
0.0 -2.0 10.9 3.07 10.7 3.13 10.4 3.19 10.2 3.26 9.9 3.32
5.0 3.0 12.6 3.22 12.3 3.29 12.0 3.36 11.7 3.43 11.4 3.49
7.0 6.0 12.6 3.07 12.3 3.14 12.0 3.20 11.7 3.26 11.4 3.33
10.0 8.0 12.6 2.85 12.3 2.91 12.0 2.97 11.7 3.02 11.4 3.08
15.0 10.0 12.6 2.67 12.3 2.73 12.0 2.78 11.7 2.84 11.4 2.89
20.0 15.0 12.6 2.32 12.3 2.36 12.0 2.41 11.7 2.46 11.4 2.51
24.0 18.0 12.6 1.96 12.3 2.00 12.0 2.04 11.7 2.08 11.4 2.12
28
-15.0 -16.0 7.2 2.61 7.1 2.66 6.9 2.72 6.7 2.77 6.6 2.83
-10.0 -11.0 8.5 2.95 8.3 3.01 8.1 3.07 7.9 3.13 7.7 3.20
-5.0 -7.0 8.9 2.66 8.7 2.71 8.5 2.77 8.3 2.82 8.0 2.88
0.0 -2.0 10.2 2.83 10.0 2.89 9.7 2.95 9.5 3.01 9.2 3.07
5.0 3.0 11.8 2.98 11.5 3.04 11.2 3.10 10.9 3.17 10.6 3.23
7.0 6.0 11.8 2.84 11.5 2.90 11.2 2.96 10.9 3.02 10.6 3.08
10.0 8.0 11.8 2.63 11.5 2.69 11.2 2.74 10.9 2.80 10.6 2.85
15.0 10.0 11.8 2.47 11.5 2.52 11.2 2.57 10.9 2.62 10.6 2.67
20.0 15.0 11.8 2.14 11.5 2.19 11.2 2.23 10.9 2.28 10.6 2.32
24.0 18.0 11.8 1.81 11.5 1.85 11.2 1.88 10.9 1.92 10.6 1.96
- 510 -
6-3. Heating capacity
6. Capacity table
OUTDOOR UNIT AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5
