Indoor unit connecting
capacity
Outdoor temperature
Indoor temperature
16.0 °CDB 18.0 °CDB 20.0 °CDB 22.0 °CDB 24.0 °CDB
kBtu/h °CDB °CWB TC IP TC IP TC IP TC IP TC IP
27
-15.0 -16.0 7.0 2.50 6.8 2.56 6.7 2.61 6.5 2.66 6.3 2.71
-10.0 -11.0 8.2 2.83 8.0 2.89 7.8 2.95 7.6 3.01 7.4 3.07
-5.0 -7.0 8.6 2.55 8.4 2.60 8.2 2.65 8.0 2.71 7.8 2.76
0.0 -2.0 9.9 2.72 9.6 2.78 9.4 2.83 9.2 2.89 8.9 2.95
5.0 3.0 11.3 2.86 11.1 2.92 10.8 2.98 10.5 3.04 10.3 3.10
7.0 6.0 11.3 2.72 11.1 2.78 10.8 2.84 10.5 2.89 10.3 2.95
10.0 8.0 11.3 2.52 11.1 2.58 10.8 2.63 10.5 2.68 10.3 2.73
15.0 10.0 11.3 2.37 11.1 2.42 10.8 2.47 10.5 2.52 10.3 2.57
20.0 15.0 11.3 2.05 11.1 2.10 10.8 2.14 10.5 2.18 10.3 2.22
24.0 18.0 11.3 1.73 11.1 1.77 10.8 1.81 10.5 1.84 10.3 1.88
NOTES:
• TC: Total Capacity (kW), IP: Input Power (kW)
• Values mentioned in the table are based on the following conditions:
– Power source of specifications: 230 V
– Pipe length: 5 m, Height difference: 0 m (Outdoor unit—Indoor unit)
• 2 or more indoor units should be connected.
• The total ability of connected a indoor unit is from 27,000 Btu/h up to 54,000 Btu/h.
• Input in the table are calculated based on the maximum indoor unit input combinations.
- 511 -
6-3. Heating capacity
6. Capacity table
OUTDOOR UNIT
AOYG36KBTA5
OUTDOOR UNIT
AOYG36KBTA5
