Fujitsu ASY7USACW Service Manual

1
SPECIFICATIONS
TYPE COOL COOL & HEAT
INDOOR UNIT ASY7FSACW ASY7USACW
OUTDOOR UNIT AOY7FSAC AOY7USAC
COOLING CAPACITY (kW) 2.10 - 2.10 2.10 - 2.10
HEATING CAPACITY (kW) 2.30 - 2.35
POWER SOURCE (V) 220 - 240 220 - 240
FREQUENCY (Hz) 50 50
RUNNING CURRENT (A)
COOLING 3.0 - 3.1 3.7 - 3.8
HEATING 3.4 - 3.6
INPUT WATTS (kW)
COOLING 0.63 - 0.67 0.78 - 0.82
HEATING 0.71 - 0.77
EER (kW/kW)
COOLING 3.33 - 3.13 2.69 - 2.56
HEATING 3.24 - 3.05
MOISTURE REMOVAL ( /hr) 1.0 1.0
AIR CIRCULATION-Hi (m
3
/hr) 415 COOL 355 HEAT 370
ELECTRICAL DATA
COMPRESSOR
DIMENSIONS
WEIGHTS
TYPE
Hermetic type, Permanent split condenser,
2 Pole, Single phase, Induction motor
CODE
80206335B 80210035C
220-240V 50Hz 220-240V 50Hz
REFRIGERANT R410A (g) 600 600
POWER SOURCE (V) 220 - 240 220 - 240
HI-SPEED (r.p.m.) 1,150 - 1,150 COOL 1,230 - 1,230 HEAT 1,280 - 1,280
INDOOR UNIT
MED-SPEED (r.p.m.) 1,080 - 1,080 COOL 1,130 - 1,130 HEAT 1,180 - 1,180
LO-SPEED (r.p.m.) 1,010 - 1,010 COOL 1,030 - 1,030 HEAT 1,080 - 1,080
QUIET (r.p.m.) 900 - 900 COOL 940 - 940 HEAT 970 - 970
OUTDOOR UNIT (r.p.m.) 770 - 800 COOL 770 - 800 HEAT 770 - 800
INDOOR UNIT
H x W x D (mm)
248 x 808 x 170
OUTDOOR UNIT
535 x 650 x 250
INDOOR UNIT
GROSS / NET
10 / 8 10 / 7.5
OUTDOOR UNIT
(kg)
27 / 24 28 / 25
FAN MOTOR

Fujitsu ASY7USACW Specifications

General

Brand	Fujitsu
Model	ASY7USACW
Category	Air Conditioner
Language	English
