OUTDOOR UNIT
17
2007.04.19
9
3
5
4
10
2
6
8
7
1
4 Fan Guard 9371187013
5 Emblem 9351355005
3 Front Panel 9371924014
8 Connecteor Cover (Cabinet) 9366398004
10 Propeller Fan Assy 9366378013
2 Protective Net 9371934013
1 Top Panel 9371925011
9 Valve Cover 9372796016
7 Side Panel R Sub Assy
93719260186 Side Panel L
9372306048
Ref. Description Part number
