Fujitsu ASYA07LACM User Manual

31
32
33
34
35
36
37
38
39
40
OUTDOOR UNIT
19
2007.04.19
Ref. Description Part number
--- Gasket (Comp) 9373266013
--- Thermal Switch 9377956019
40 Accum Support Assy 9372252017
39 Capilarry Assy 9373729211
38 Pressure Switch Assy 9373729044
36 Solenoid 9900165079
37 4-Way Valve 9900163013
--- Thermister Holder Pipe 313714262805
31 Compressor Assy 9373262015
--- Compressor pressure switch 9900186012
--- Compressor thermal switch 9373263012
--- Thermistor Valve 9900194017
--- Thermistor discharge 9704219039
--- Special Nut M8 (Comp) 9355091008
32 Terminal Cover (Comp) 9373264019
33 Receiver Tank Assy 9373426011
34 Strainer Assy 9366602019
35 Accumulator 9368391003
