OUTDOOR UNIT
43
42
41
44
20
2007.04.19
41 Compressor Cover A 9373730019
42 Compressor Cover B 9373730026
43 Joint Pipe (3Way) Assy 9373729129
44 Expansion Valve Assy 9373729068
Ref. Description Part number
