21
23
26
24
25
27
22
2010.09.15
13
21 Evaporator Total Assy (09) 9316893009
22 Joint Pipe Assy (09) 9316923010
21 Evaporator Total Assy (12) 9316893016
22 Joint Pipe Assy (12) 9317190015
23 Filter Guide 9316578005
25
24
Evaporator Holder R 9316565005
27 Room thermistor Holder 9316895003
26 Evaporator Holder L 9316564008
Rear Bracket 9316566019
Ref. Description Part number
INDOOR UNIT
Evaporator
