1. Appearance
2. SERVICE PANEL removal
Remove the mounting screws.
Remove the SERVICE PANEL
by sliding downward.
06-01
6. DISASSEMBLY PROCESS
Before servicing the unit, turn the power supply switch OFF,
Then, do not touch electric parts for 10 minutes due to the risk of electric shock.
WARNING
Hooks (4 places)
Screws
(serrated)
Makre sure that the wires are not pinched when you close the SERVICE PANEL.
Caution
