8. COMPRESSOR CONTROL
(1). OPEARTION FREQUENCY RANGE
The operation frequency of the compressor is different based on the operation mode as
shown in the table 10.
Cooling Heating
Min Max Min Max
Dry
07/09LCC, 09LDC 18Hz 80Hz 18Hz 130Hz 33H z
12LCC, 12LDC 18Hz 96Hz 18Hz 130Hz 33Hz
14LCC, 18LCC 18Hz 90Hz 18Hz 119Hz 24 Hz
ASYA07/09LCC 56Hz 74Hz 87Hz 97Hz 108Hz 119Hz
ASYA12LCC 56Hz 64Hz 74Hz 87Hz 108Hz 120Hz
ASYB09/12LDC 56Hz 74Hz 87Hz 97Hz 108Hz 119Hz
ASYA07/09LCC 80sec 60sec 60sec 180sec 60sec 60sec
ASYA12LCC 80sec 30sec 30sec 30sec 50sec 60sec
ASYB09/12LDC 80sec 60sec 60sec 180sec 60sec 60sec
(Table 10 : Compressor Operation Frequency Range)
(2). OPEARTION FREQUENCY CONTROL AT START UP
The compressor frequency soon after the start-up is controlled as shown in the figure 10.
(Fig.10 : Compressor Control at Start-up)
Time
Time Time Time
Time
Time
(Frequency)
(Time)
Frequency
Frequency
Frequency Frequency
Frequency
Frequency
Time Time
Time Time Time Time
Frequency
Frequency
Frequency
Frequency
Frequency
Frequency
05-09
ASYA14/18LCC 40Hz 59Hz 72Hz 80Hz 101Hz 110Hz
ASYA14/18LCC 60sec 40sec 40sec 60sec 150sec 60sec
