Fujitsu ASYB12LDC - Page 72

(2/2)
< Capacity >
< Input >
*Both capacity and input decrease when temperature is 19 or less degrees C, for compressor
frequency restrictions operate.
*Both capacity and input decrease when temperature is 43 or more degrees C, as compressor speed is
decreased due to current release protection.
Cooling
60%
70%
80%
90%
100%
110%
120%
130%
140%
150%
10 15 20 25 30 35 40 45
Capacity(%)
30%
40%
50%
60%
70%
80%
90%
100%
110%
120%
10 15 20 25 30 35 40 45
Input(%)
43
19
19
43
Indoor:27/19 C
Outdoor DB( C)
Indoor:27/19 C
Outdoor DB( C)
08-12
