Models: ASYG07KETA, ASYG09KETA, ASYG12KETA,
ASYG14KETA, ASYG07KETA-B, ASYG09KETA-B,
ASYG12KETA-B, and ASYG14KETA-B
(950)
Outline of indoor unit
327
273273
54
(295)
43
43
9.5
220
for pipe inlet Ø65 for pipe inlet Ø65
182 182
356346106 142
63 63
950
295
230
3.0
Unit: mm
2-4. Wall mounted type
- (01-29) - 2. Dimensions
GENERAL
INFORMATION
GENERAL
INFORMATION
