Front panel B
Panel cover
Front panel
Frontpanel
cover
Grille
clamper L
Grille
clamper R
22
21
Item no. Part no. Part name Service part
21 9387473001 Air filter ♦
22 9387756005 Intake grille assy ♦
3-4. Wall mounted type - (02-25) - 3. Indoor unit parts list
