DIMENSIONS
unit : mm
260
198
790
2011.01.21 2
INDOOR UNIT
OUTDOOR UNIT
Drain pipe diameter
16.2 mm
Liquid pipe diameter : 6.35 mm
Gas pipe diameter : 9.52 mm
540
66019.5
29068
