722010.10.08
INDOOR UNIT
COMPACT WALL MOUNTED
ASYG07LJCA
ASYG09LJCA
ASYG12LJCA
21
22 Joint Pipe Assy
Evaporator Total Assy
23
Holder (Room Thermistor)
Thermistor Assy
24
25 Evaporator Holder R
26
Filter Guide
Parts number
DescriptionRef
9317820011
9317838009
9317652001
9317651004
9317650007
9317649001
Rear Bracket
27
28
Evaporator Holder L
9316895003
9900563004
21
27
28
22
23
24
26
25
