712010.10.07
PARTS
INDOOR UNIT
COMPACT WALL MOUNTED
ASYG07LJCA
ASYG09LJCA
ASYG12LJCA
1
2
Front Panel
Front Panel Total Assy
3
Wire Cover
Wire Shield
4
5
Air Filter
6
Intake Grille Assy
Parts numberDescriptionRef
9318267051
9317642057
9318268034
9316906006
9317644013
9317643016
7
Clamper Grille
8
9
Receiver Window
Panel Cover
Air Clean Filter Assy
9317646017
9317663007
9317664011
9305642045
9317250009
10
Bracket Panel
Remote Control
9317665001
11
12
--
Remote Control Holder
9379219006
1
4
5
3
2
4
11
12
10
6
7
9
8
