Page #18 background imageLoading...
Page #18 background image
40
38
32
33
35
39
31
34
37
36
INDOOR UNIT
Casing assy
17
Fan Guard 9332551006
39
40
Step Motor 9900725006
36
Drain Hose Assy 9316904002
37
Drain Cap 9316177017
31
Casing Cover B 9332557008
32
Casing Cover F 9332558005
33
R and L Louver 9332535006
Casing 9332534009
Motor Cover 9316601000
Motor Cover 9316568006
38
34
35
Ref. Description Part number
2012.02.14
