46
43
18
41
Evaporator Total Assy (09)
9316893085
42
Evaporator Total Assy (12)
9316893092
46 Rear Bracket 9332540017
44
43
9332538007
45 Evaporator Holder L
Evaporator Holder R
9332539004
Earth Terminal 9316579002
47 Filter Guide 9332541007
Ref. Description Part number
2012.02.14
41
42
INDOOR UNIT
Evaporator
ASYG09LLCA
ASYG12LLCA
44
45
47
