Page #14 background imageLoading...
Page #14 background image
22
24
21
23
INDOOR UNIT
Fan
13
Fan Motor 9603180003
Crossflow Fan Assy 9316830004
Bearing C Assy 9306628017
24
21
Casing Assy 9332613018
22
23
Ref. Description Part number
2013.09.30
