DIMENSIONS
15.8 to 16.7
2013.09.30 2
INDOOR UNIT
Drain hose
OUTDOOR UNIT
Diameter
Outside
Inside : 13.8 mm
15
663 mm
600 mm
20
293 mm
68
454 mm
535 mm
262 mm
206 mm820 mm
