2013.09.30 17
21 Reactor Assy 9900787028
22 PCB Holder 9332506006
23 Main PCB with Terminal (09) 9709435137
23 Main PCB with Terminal (07) 9709435120
23 Main PCB with Terminal (12) 9709435144
-- Thermistor Assy 9900719029
-- Outdoor Thermistor 9900717025
24 Heat Sink B 9332522006
Ref. Description Part number
OUTDOOR UNIT
23
22
23
24
21
