En-3
AIR CONDITIONER Wall Mounted Type
OPERATING MANUAL
CAUTION
• To prevent malfunction or damage of the remote controller:
- Place remote controller at where will not be exposed to
direct sunlight or excessive heat.
- Remove batteries if the product is not going to be used for
an extended period.
- Exhausted batteries must be removed immediately, and
be disposed according to the local laws and regulations of
your region.
• If leaking battery À uid comes in contact with your skin, eyes,
or mouth, immediately rinse with plenty of clean water, and
consult your physician.
• Obstacles such as a curtain or wall between the remote
controller and the indoor unit may affect the appropriate
signal transmission.
• Do not apply strong shocks to the remote controller.
• Do not pour water on the remote controller.
• Do not attempt to recharge dry batteries.
Battery (R03/LR03/AAA × 2) loading and remote controller preparation
1
4
2
3
5
7
6
5
Press CLOCK ADJUST button to start clock setting.
6
Set the time by pressing SELECT button.
Each time you press the button, the value increases or
decreases 1 minute. With pressing and holding the button, the
value increasesor decreases 10 minutes.
7
Press the CLOCK ADJUST button again to complete the clock
setting.
Notes:
• Use speci¿ ed type of battery only.
• Do not use new battery and used battery together.
• Batteries can be used about 1 year in ordinary use.
• If the remote control range noticeably got shorten, replace the
batteries, and press RESET button.
You can quickly start the operation with following 3 steps:
Remote Controller Overview and Operations
1 START/STOP button
2 MODE button
Switches operation mode in following order.
AUTO COOL DRY FAN HEAT
Notes in HEAT mode:
• At the beginning of the operation, the indoor unit operates at very
low fan speed for about 3–5 minutes for preparation, and then
switches to the selected fan speed.
• Automatic defrosting operation overrides the heating operation when
it is necessary.
Note in COOL mode:
Indoor unit fan may stop from time to time to perform indoor-unit-
fan control for energy saving that enables power-saving operation by
stopping the rotation of the indoor unit fan when the outdoor unit is
stopped.
(continued)
In initial setting, this function is activated.
To inactivate the function, consult the installer or authorized service
personnel.
Even if the setting is changed, if the fan speed is set to “AUTO” in
COOL or DRY mode, this function still works to suppress the diffusion
of circulated indoor humidity.
3 SET TEMP. (temperature) buttons
Set desired temperature.
In COOL/DRY mode, the value needs to be set at lower temperature
than current room temperature, and in HEAT mode, the value needs
to be set at higher temperature than current room temperature.
Otherwise, corresponding operation mode does not start to work.
Temperature setting range
AUTO/COOL/DRY 18–30 °C
HEAT 16–30 °C
*:Temperature control is not available in FAN mode.
18
15
16
14
19
2
9
10
13
8
3
11
12
1
5
6
4
7
17
To Next Page
