PARTS
8
4
3
9
5
10
7
1
2
INDOOR UNIT
2014.03.14 13
5
8
9
7 Intake Grille (FUJITSU) 9333052007
6
Front Panel Sub Assy (FUJITSU)
9332994001
Bracket panel
3
Wire Cover 9332894004
Wire shield
Electric Filter Holder 9332911008
4 Air Clean Filter Assy 9317250009
1 Remote Control 9319208008
2 Remote Control Holder 9318912005
Ref. Description Part number
Air Filter 9332875010
Louver with Shaft cover 9333353005
10 Diffuser Assy 9332998009
6
