DIMENSIONS
2013.09.12 2
INDOOR UNIT
OUTDOOR UNIT
15.8 to 16.7
Drain hose
Diameter
Outside
Inside : 13.8 mm
600
268 mm
203 mm840 mm
20
290 mm
790 mm
20
540 mm
620 mm
62
