INDOOR UNIT
Evaporator
Fan
Fan Motor 9603269005
Crossflow Fan Assy 9316830004
Bearing C Assy 9306628017
25
22
Evaporator Total Assy 933298901421
Casing Assy 9333009001
23
24
Ref. Description Part number
152013.09.24
25
24
23
21
22
