INDOOR UNIT
ASYG09LZCA
ASYG12LZCA
Control box
112016.06.08
Terminal 990072002514
Control Box12
Cover shield
11 9318757019Control Cover
9380996002
Main PCB (ASYG09LZCA)
970962216213
Main PCB (ASYG12LZCA)
970962217913
16 Room Thermistor Holder 9379930000
Ref. Description Part number
15
-- Thermistor Assy 9900627003
Display Assy 9709642023
13
12
11
16
15
14
