Fujitsu ASYG09LZCA Service Manual

PARTS
INDOOR UNIT
ASYG09LZCA
ASYG12LZCA
2016.06.15 10
5
8
9
7
Intake Grille with logotype 9333052045
6 Front Panel Sub Assy 9320459000
Bracket panel
3
Wire Cover 9318786002
Wire shield
Electric Filter Holder 9332911008
4 Air Clean Filter Assy 9317250009
1
Remote Control 9320360023
2 Remote Control Holder 9318912005
Ref. Description Part number
Air Filter 9380997009
Louver 9318849028
10 Diffuser Assy 9319232096
8
4
3
5
7
1
2
6
9
10
OPTION Air Clean Filter
APPLE-CATECHIN FILTER (Every 3 months)
: UTR-FA16 (9315361035)
ION DEODRIZATION FILTER “light blue” (Every 3 months)
: UTR-FA16-2 (9315361042)

Fujitsu ASYG09LZCA Specifications

General

Brand	Fujitsu
Model	ASYG09LZCA
Category	Air Conditioner
Language	English
