INDOOR UNIT
ASYG09LZCA
ASYG12LZCA
Casing total assy
13
31 Outlet Cover Assy 9319776002
33
32
Casing Assy 9319172101
Motor Case Assy 9319173085
Ref. Description Part number
2016.06.08
