Fujitsu ASYG12LECB

3
4
10
6
15
14
16
12
11
2
1
9
8
13
5
PARTS
OUTDOOR UNIT
2012.12.26 17
5 Top Panel Assy 9317761017
3 Front Panel Assy 9317760041
2 Protective Net 9318635003
6
7
Cabinet Left Assy 9318247008
4 Emblem 9319151007
Switch Cover A Assy 9317795005
8 Switch Cover B 9317582001
1
Thermistor Holder (12) 9313954031
1 Thermistor Holder (09) 9313954048
Ref. Description Part number
9 Grip 9317588003
10 Cabinet Right Assy 9317759007
15 Heater Holder A 9318631005
16 Heater Holder B 9318651003
14 Heater Unit Assy 9900616007
12 Propeller Fan 9313808013
13 Base Assy 9316885059
11 Fan Motor 9602864003
Ref. Description Part number
7
