Fujitsu ASYG12LECB - Page 19

OUTDOOR UNIT
2012.12.26 18
-- Outdoor Thermistor 9900544010
23 Terminal 9900435028
24 Heat Sink A 9314410017
25 Heat Sink B 9314090011
Main PCB (AOYG09)
-- Thermistor Assy 9900614003
21 9708753331
Main PCB (AOYG12)21 9708753348
22 PCB Holder 9313074029
Ref. Description Part number
22
24
25
21
23
26 Reactor Assy 9900611019
26
