OUTDOOR UNIT
AOYG09LECAN
2012.12.27 19
32 Compressor Assy 9317619004
34 3-way Valve Assy 9314022012
37 Pulse Motor Valve Assy 9314557019
36 Solenoid 9970055010
31 Condenser Total Assy 9318711004
38 Expansion Valve Coil 9970095030
35 4-way Valve Assy 9314093050
33 2-way Valve Assy 9314554018
Ref. Description Part number
32
31
33
37
34
38
35
36
