42
41
43
47
44
48
45
46
OUTDOOR UNIT
AOYG12LECAN
2012.12.27 20
42 Compressor Assy 9317619004
44 3-way Valve Sub Assy 9317109000
47 Pulse Motor Valve Assy 9332368000
46 Solenoid 9970055010
41 Condenser Total Assy 9332359008
48 Expansion Valve Coil 9970095030
45 4-way Valve Assy 9332365009
43 2-way Valve Assy 9332371000
Ref. Description Part number
To Next Page
