INDOOR UNIT
FLOOR
AGYG09LVCA
AGYG12LVCA
AGYG14LVCA
2010.09.17 13
740 mm
200
600 mm
INDOOR UNIT
FLOOR / CEILING
ABYG14LVTA
ABYG18LVTA
ABYG18LVTB
Unit : mm
990 mm
900 mm
500 mm
655 mm
530 mm
200175
199 mm
Rear view
