DIMENSIONS
unit : mm
282
185
870
2011.09.15 2
INDOOR UNIT
OUTDOOR UNIT
Drain hose length :
600 mm
Drain pipe diameter
Inside : 14.2 mm
Outside : 16.2 mm
20
290
790
20
540
620
62
