Fujitsu ASYG12LTCB User Manual

-
(
01 - 11
)
-
WALL MOUNTED TYPE AS

G09-14LT
WALL MOUNTED TYPE AS

G09-14LT
HEATING CAPACITY6-2.
MODEL

:
AS

G09LT
MODEL

:AS

G12LT
MODEL

:AS

G14LT
AFR : Air Flow Rate (m
3
/min)
TC : Total Capacity (kW)
IP : Input Power (kW)
AFR 13.3
Indoor temperature
(°CDB) 16 18 20 22 24
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-25 -26 2.31 1.17 2.26 1.19 2.20 1.21 2.15 1.24 2.09 1.26
-20 -21 2.84 1.24 2.77 1.26 2.70 1.29 2.63 1.32 2.57 1.34
-15 -16 3.36 1.31 3.28 1.34 3.20 1.37 3.12 1.39 3.04 1.42
-10 -11 3.89 1.40 3.79 1.43 3.70 1.46 3.61 1.49 3.52 1.51
-5 -7 4.25 1.45 4.15 1.48 4.04 1.51 3.94 1.54 3.84 1.57
0 -2 4.36 1.44 4.26 1.47 4.16 1.50 4.05 1.53 3.95 1.56
5 3 5.17 1.50 5.04 1.53 4.92 1.56 4.80 1.59 4.67 1.62
7 6 5.67 1.54 5.54 1.57 5.40 1.61 5.27 1.64 5.13 1.67
10 8 6.27 1.51 6.12 1.54 5.97 1.57 5.82 1.60 5.67 1.63
15 10 6.49 1.41 6.34 1.44 6.18 1.47 6.03 1.50 5.88 1.53
AFR 14.2
Indoor temperature
(°CDB) 16 18 20 22 24
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-25 -26 3.68 2.00 3.59 2.04 3.50 2.08 3.41 2.12 3.33 2.17
-20 -21 4.10 2.02 4.00 2.06 3.90 2.10 3.80 2.14 3.71 2.18
-15 -16 4.62 2.02 4.51 2.06 4.40 2.10 4.29 2.15 4.18 2.19
-10 -11 4.69 1.94 4.57 1.98 4.46 2.02 4.35 2.06 4.24 2.10
-5 -7 4.77 1.87 4.66 1.91 4.54 1.95 4.43 1.99 4.32 2.02
0 -2 4.89 1.80 4.77 1.84 4.66 1.88 4.54 1.91 4.42 1.95
5 3 6.07 1.86 5.92 1.90 5.78 1.94 5.64 1.98 5.49 2.02
7 6 6.83 1.92 6.66 1.96 6.50 2.00 6.34 2.04 6.18 2.08
10 8 7.5 4 1.9 4 7. 36 1. 98 7.18 2.0 2 7.0 0 2. 0 6 6 .8 2 2 .10
15 10 7.8 2 1.9 5 7.6 3 1.9 9 7. 4 4 2.0 3 7. 26 2 .07 7.07 2 .11
AFR 15.8
Indoor temperature
(°CDB) 16 18 20 22 24
Outdoor temperature
(°CDB) (°CWB) TC IP TC IP TC IP TC IP TC IP
-25 -26 4.73 2.09 4.61 2.14 4.50 2.18 4.39 2.22 4.28 2.27
-20 -21 5.15 2.11 5.02 2.16 4.90 2.20 4.78 2.24 4.66 2.29
-15 -16 5.67 2.14 5.54 2.19 5.40 2.23 5.27 2.27 5.13 2.32
-10 -11 6.06 2.18 5.92 2.23 5.78 2.27 5.63 2.32 5.49 2.36
-5 -7 6.32 2.28 6.17 2.33 6.02 2.38 5.87 2.43 5.72 2.48
0 -2 6.38 2.48 6.23 2.53 6.08 2.58 5.93 2.63 5.77 2.68
5 3 6.97 2.32 6.81 2.37 6.64 2.42 6.47 2.47 6.31 2.52
7 6 7.35 2.17 7.18 2.21 7.00 2.26 6.83 2.31 6.65 2.35
10 8 8.12 1.9 4 7.9 3 1. 9 8 7.74 2 .02 7.5 4 2.0 6 7.3 5 2 .10
15 10 8.42 1.95 8.22 1.99 8.02 2.03 7.82 2.07 7.62 2.11

Fujitsu ASYG12LTCB Specifications

General

Brand	Fujitsu
Model	ASYG12LTCB
Category	Air Conditioner
Language	English
