INDOOR UNIT
ASYG09LZCA
ASYG12LZCA
Motor case assy
14
Louver Gear B 9316616004
42
45
Step Motor (R&L)
50
Link A 9317507004
43
Step Motor (Louver)46
Step Motor (Diffuser)
9900384135
9900384142
9900139230
49
Gear A 9309994003
44
Louver Gear A 9318749007
41
Gear Cover A 9318748000
Gear Cover B 9318750003
Louver Link Holder 9319150000
Motor Case 9318746020
51
47
48
Ref. Description Part number
