Fujitsu ASYG12LZCA Service Manual

OUTDOOR UNIT
AOYG09LZCAN
AOYG12LZCAN
2016.06.09 19
38
31
34
33
37
32
36
35
38 Compressor Assy 9317117005
37 3-way Valve Sub Assy 9317109000
33 Pulse Motor Valve Assy 9332368048
4-way Valve Assy 9315311092
35 Solenoid 9970110047
31 Condenser Total Assy 9317089098
32 Expansion Valve Coil 9970095030
36
34 2-way Valve Assy 9332371000
Ref. Description Part number
