6. SYSTEM DESIGN
Ideal warm airow

Tempe-
rature(°C)
40
30
20
Tempe-
rature(°C)
40
30
20
2m 2m
Without Auto Louver With Auto Louver
[Condition]
Model (Indoor unit): AR*G12LLTA
Outdoor temperature: 2°C
Operation contents: Heating
Set temperature: 30°C
ir ow i
[Condition]
Model (Indoor unit): AR*G12LLTA
Model (Auto louver grille): UTD-GXSA-W
Outdoor temperature: 2°C
Operation contents: Heating
Set temperature: 30°C
ir ow i
ertica ap ownward
Flexible installation

Auto Louver Grille can be connected either directly with indoor unit or through the rectangular
duct.
(b) Connection with rectangular duct(a) Direct connection to flange
* 1󲦇
Attachment is not necessary.
Flange of Slim Duct*1
Slim Duct
cable
Auto Louver Grille
Bracket Flame
Grille
｝
* 2:
Rectangular duct*2(Field supplied)
Slim Duct
cable
Auto Louver Grille
Bracket Flame
Grille
｝
within 1m
Length of connecting duct must be within 1m
- (06 - 143) -
