6. SYSTEM DESIGN
SPECIFICATIONS

Model name UTD-GXSA-W UTD-GXSB-W
Power Supply Connecting with Control box of indoor unit
Fixing of Auto Louver Grille crew ing to ange or ectanguar duct
Extension Square Duct Limit 1.0m (Max. duct length between indoor unit and Grille)
Net Dimension
(H x W x D)
mm
(inch)
180x683x(84+9)
[7-3/32x26-7/8x(3-5/16+11/32)]
180x883x(84+9)
[7-3/32x34-3/4x(3-5/16+11/32)]
Weight
Net
kg
(lb.)
2.0 (4.4) 2.5 (5.6)
Gross 3.0 (6.7) 3.5 (7.8)
Color White
Louver Motor Stepping Motor
Material Flame retardant ABS
Accessories Fitting Flame, etc.
Operation
range
Cooling
°C (°F) 18 to 32 (64 to 90)
% RH 80% or less
Heating °C (°F) 16 to 30 (60 to 88)
- (06 - 144) -
SYSTEM DESIGN SYSTEM DESIGN
