4. Capacity table
Capacity tables show each of following values calculated based on the outdoor temperature and the
indoor temperature, under given Airflow Rate (AFR):
For cooling capacity: Total Capacity (TC), Sensible Heat Capacity (SHC), and Input Power (IP)
For heating capacity: Total Capacity (TC) and Input Power (IP)
4-1. Cooling capacity
¢
Model: ASYG30KMTA
AFR
m
3
/h
1,330
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 6.61 6.12 0.78 6.85 6.14 0.80 7.00 6.16 0.81 7.39 6.45 0.82 7.78 6.74 0.84 8.22 6.96 0.85 8.87 7.29 0.87
-10 6.27 5.69 0.95 6.49 5.71 0.97 6.64 5.73 0.98 7.01 6.00 1.00 7.38 6.27 1.02 7.79 6.48 1.03 8.41 6.78 1.05
0 5.59 4.84 1.28 5.78 4.86 1.31 5.91 4.87 1.33 6.24 5.10 1.35 6.57 5.33 1.38 6.94 5.51 1.40 7.49 5.76 1.43
5 5.42 4.65 1.32 5.61 4.67 1.35 5.74 4.68 1.37 6.06 4.91 1.40 6.38 5.13 1.42 6.73 5.29 1.44 7.27 5.54 1.47
10 5.25 4.47 1.36 5.44 4.48 1.39 5.56 4.50 1.41 5.87 4.71 1.44 6.18 4.92 1.46 6.53 5.08 1.48 7.05 5.32 1.51
15 6.52 5.33 1.66 6.75 5.35 1.70 6.91 5.36 1.73 7.29 5.61 1.76 7.67 5.87 1.79 8.10 6.06 1.81 8.75 6.34 1.85
20 7.79 6.19 1.97 8.07 6.21 2.01 8.25 6.22 2.04 8.71 6.52 2.08 9.17 6.81 2.11 9.68 7.04 2.15 10.45 7.37 2.19
25 7.46 5.99 2.03 7.72 6.01 2.08 7.90 6.02 2.11 8.34 6.31 2.15 8.78 6.59 2.19 9.27 6.81 2.22 10.01 7.13 2.27
30 7.13 5.78 2.10 7.38 5.81 2.15 7.55 5.82 2.18 7.97 6.10 2.22 8.39 6.37 2.26 8.86 6.58 2.29 9.57 6.89 2.34
35 6.80 5.58 2.17 7.04 5.60 2.22 7.20 5.62 2.25 7.60 5.88 2.29 8.00 6.15 2.33 8.45 6.35 2.36 9.12 6.65 2.41
40 6.36 5.21 2.27 6.59 5.23 2.32 6.74 5.24 2.35 7.11 5.49 2.39 7.49 5.74 2.43 7.91 5.92 2.47 8.54 6.20 2.52
46 5.84 4.76 2.38 6.04 4.78 2.44 6.18 4.79 2.48 6.52 5.02 2.52 6.87 5.24 2.56 7.25 5.41 2.60 7.83 5.67 2.65
¢
Model: ASYG36KMTA
AFR
m
3
/h
1,330
Indoor temperature
°CDB 18 21 23 25 27 29 32
°CWB 12 15 16 18 19 21 23
Outdoor temperature
°CDB
TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP TC SHC IP
kW kW kW kW kW kW kW
-15 7.77 6.96 1.06 8.05 6.98 1.08 8.23 7.00 1.10 8.69 7.33 1.12 9.14 7.50 1.14 9.66 7.91 1.15 10.43 8.28 1.18
-10 7.37 6.47 1.28 7.63 6.50 1.31 7.80 6.51 1.33 8.24 6.82 1.36 8.67 6.98 1.38 9.16 7.36 1.40 9.89 7.71 1.43
0 6.56 5.51 1.74 6.79 5.53 1.78 6.95 5.54 1.81 7.34 5.81 1.84 7.72 5.94 1.87 8.16 6.27 1.89 8.81 6.56 1.93
5 6.37 5.30 1.79 6.59 5.32 1.83 6.74 5.33 1.86 7.12 5.58 1.89 7.49 5.71 1.92 7.91 6.03 1.95 8.54 6.31 1.99
10 6.17 5.09 1.84 6.39 5.11 1.89 6.54 5.12 1.92 6.90 5.36 1.95 7.26 5.49 1.98 7.67 5.79 2.01 8.28 6.06 2.05
15 7.66 6.18 2.26 7.93 6.20 2.31 8.11 6.21 2.34 8.57 6.51 2.38 9.02 6.66 2.42 9.52 7.03 2.46 10.28 7.35 2.51
20 9.15 7.26 2.67 9.48 7.29 2.73 9.69 7.31 2.77 10.23 7.66 2.82 10.77 7.83 2.87 11.38 8.26 2.91 12.28 8.65 2.97
25 8.77 6.96 2.76 9.07 6.99 2.82 9.28 7.00 2.87 9.80 7.34 2.92 10.31 7.50 2.97 10.89 7.92 3.01 11.76 8.29 3.07
30 8.38 6.66 2.85 8.67 6.68 2.92 8.87 6.70 2.96 9.36 7.02 3.01 9.86 7.18 3.06 10.41 7.57 3.11 11.24 7.93 3.17
35 7.99 6.21 2.94 8.27 6.24 3.01 8.46 6.25 3.06 8.93 6.55 3.11 9.40 6.70 3.16 9.93 7.07 3.21 10.72 7.40 3.27
40 7.47 6.32 3.07 7.74 6.34 3.15 7.92 6.36 3.19 8.36 6.66 3.25 8.80 6.81 3.30 9.29 7.19 3.35 10.03 7.53 3.42
46 6.86 6.28 3.23 7.10 6.30 3.31 7.26 6.32 3.36 7.67 6.62 3.42 8.07 6.77 3.47 8.52 7.14 3.52 9.20 7.48 3.60
- 7 -
4-1. Cooling capacity 4. Capacity table
WALL MOUNTED ASYG30-36KMTA WALL MOUNTED ASYG30-36KMTA
