2003.06.11
- 24 -
AOG54APA3L AOY54APA3L AOT54APA3L
2 Fan Cover 9352159015 9352159015 9365905012
4 Emblem-Rear 313791088308 9351355005 9351355005
5 Cabinet-A, Painted 9352146015 9352146015 9352146015
6 Cabinet-C, Painted 9352149016 9352149016 9352149016
9 Cabinet-B, Painted 9352147012 9352147012 9352147012
12 Base Assy, Painted 9352136016 9352136016 9352136016
15 Dryer 9368111014 9368111014 9368111014
16-1 Condenser-A Assy 9369544002 9369544002 9369544002
16-2 Condenser-B Assy 9369545009 9369545009 9369545009
18 Suction Pipe Assy 9364514000 9364514000 9364514000
19 Capillary Tube 9370740011 9370740011 9370740011
20 Discharge Pipe Assy 9370950038 9370950038 9370950038
26 Compressor Cover-A 9370774030 9370774030 9370774030
29 Separate Wall 9355277013 9355277013 9355277013
30 Blower Cover, Painted 9352151019 9352151019 9352151019
32 Control Box Metal 9352134012 9352134012 9352134012
34 Capacitor (Fan Motor) 9357965024 9357965024 9357965024
36 Cord Holder Metal 9356934007 9356934007 9356934007
39 Propeller Fan Assy 9366378013 9366378013 9366378013
41 Fan Motor Assy-Out 9600832028 9600832028 9600832028
45 Bracket (Motor) Assy 9368108007 9368108007 9368108007
46-3 Compressor-C Assy 9370067002 9370067002 9370067002
47-2 Rubber (Discharge Pipe) 313185159802 313185159802 313185159802
48 Bracket (Coupler) Assy 9355281010 9355281010 9355281010
55 Special Nut M8 (For Comp.) 9355091008 9355091008 9355091008
107 Rubber Seat-A (For Comp.) 9364084008 9364084008 9364084008
108 Sleeve-A (For Comp.) 9364085005 9364085005 9364085005
109 Terminal Cover (For Comp.) 9364087009 9364087009 9364087009
111 Terminal Packing 9364086002 9364086002 9364086002
185 Rubber Bushing 313005066051 313005066051 313005066051
259 Muffler 9368082000 9368082000 9368082000
320 Wire Clamp Metal 313483219905 313483219905 313483219905
333-2 Accumulator (B) 9362425001 9362425001 9362425001
334 Suction Pipe-B 9352287008 9352287008 9352287008
373 Grip 9352157004 9352157004 9352157004
401 Terminal-2P 9701971015 9701971015 9701971015
405 Clamp No.1763 313816345304 313816345304 313816345304
407 Clamp (Cable) No.1259 313739340109 313739340109 313739340109
450 Discharge Pipe-A 9370951059 9370951059 9370951059
527 Protection Net 9352163012 9352163012 9352163012
549 Thermistor-Outdoor 9352426001 9352426001 9352426001
620 Inlet Pipe (Cond.) Assy 9353183002 9353183002 9353183002
646 Compressor Cover-B 9370774047 9370774047 9370774047
653-1 Bolt (Fan Motor Fixing) 9385089020 9385089020 9385089020
734 Cabinet Top Plate 9352161018 9352161018 9352161018
735 Distributor Assy 9353187000 9353187000 9353187000
788 Thermistor-Overheat 9354061002 9354061002 9354061002
790-1 Belt Heater-A 9361140042 9361140042 9361140042
791 Magnetic Relay 9363277005 9363277005 9363277005
803 Cabinet-D, Painted 9352150012 9352150012 9352150012
805 Blower Cover Corner 9352160011 9352160011 ---------
808 Inlet Pipe (Accumulator) 9352285004 9352285004 9352285004
809 Ball Valve-A 9357976006 9357976006 9357976006
810 Ball Valve-B 9357982007 9357982007 9357982007
813 Cabinet Hook 9352148002 9352148002 9352148002
815 Terminal-8P 9363276022 9363276022 9363276022
816 Wire Clamp Metal 313584219902 313584219902 313584219902
817 Thermostat Fixture 9352164019 9352164019 9352164019
819 Valve-A Coupl. Pipe 9370739022 9370739022 9370739022
821 Joint Pipe Assy 9352284007 9352284007 9352284007
822 Fan Cover Fixture-A 9352158018 9352158018 ---------
823-2 Fuse Holder 0500063024 0500063024 0500063024
824-4 Fuse 0600222529 0600222529 0600222529
826 Condensing Pipe-B 9353215000 9353215000 9353215000
863 Joint Pipe (Capillary)-B 9353206008 9353206008 9353206008
880-1 Network 9700987017 9700987017 9700987017
Ref.
No.
Description
Ord.
Q'ty
Part No.
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
OUTDOOR UNIT
AOG54APA3L
AOY54APA3L
AOT54APA3L
To Next Page
