AOG54RPA3L AOY54RPA3L AOT54RPA3L
2003.06.11
- 25 -
When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
OUTDOOR UNIT
AOG54RPA3L
AOY54RPA3L
AOT54RPA3L
2 Fan Cover 9352159015 9352159015 9365905012
4 Emblem-Rear 313791088308 9351355005 9351355005
5 Cabinet-A, Painted 9352146015 9352146015 9352146015
6 Cabinet-C, Painted 9352149016 9352149016 9352149016
9 Cabinet-B, Painted 9352147012 9352147012 9352147012
12 Base Assy, Painted 9352136016 9352136016 9352136016
15 Dryer 9368111014 9368111014 9368111014
16-1 Condenser-A Assy 9355338011 9355338011 9355338011
16-2 Condenser-B Assy 9353363008 9353363008 9353363008
18 Suction Pipe Assy 9364514000 9364514000 9364514000
21 Discharge Pipe-B 9368331009 9368331009 9368331009
26 Compressor Cover-A 9370774030 9370774030 9370774030
29 Separate Wall Assy 9355277013 9355277013 9355277013
30 Blower Cover, Painted 9352151019 9352151019 9352151019
32 Control Box Metal 9352134012 9352134012 9352134012
36 Cord Holder Metal 9356934007 9356934007 9356934007
39 Propeller Fan Assy 9366378013 9366378013 9366378013
41 Fan Motor Assy-Out 9600832028 9600832028 9600832028
45 Bracket (Motor) Assy 9368108007 9368108007 9368108007
46-3 Compressor-C Assy 9370067002 9370067002 9370067002
48 Bracket (Coupler) Assy 9355281010 9355281010 9355281010
55 Special Nut M8 (For Comp.) 9355091008 9355091008 9355091008
64 Capacitor (Fan Motor) 9357965024 9357965024 9357965024
107 Rubber Seat-A (For Comp.) 9364084008 9364084008 9364084008
108 Sleeve-A (For Comp.) 9364085005 9364085005 9364085005
109 Terminal Cover (For Comp.) 9364087009 9364087009 9364087009
111 Terminal Packing 9364086002 9364086002 9364086002
182 Clamp No.249 313361271505 313361271505 313361271505
184-1 Thermo. Spring-A 313728262708 313728262708 313728262708
185 Rubber Bushing 313005066051 313005066051 313005066051
236 Controller PCB Assy 9704764089 9704764089 9704764089
272 Strainer Assy 9354139008 9354139008 9354139008
330 Inlet Pipe (Cond.)-A 9353310002 9353310002 9353310002
333 Accumulator 9350363018 9350363018 9350363018
333-2 Accumulator Assy (B) 9362425001 9362425001 9362425001
334 Suction Pipe-B 9352287008 9352287008 9352287008
343 Solenoid Coil 9359616108 9359616108 9359616108
344-2 4-Way Valve 9353532008 9353532008 9353532008
354 Pressure Switch 9704045003 9704045003 9704045003
373 Grip 9352157004 9352157004 9352157004
381 Locking Spacer 313209391506 313209391506 313209391506
405 Clamp No.1763 313816345304 313816345304 313816345304
407 Clamp (Cable) No.1259 313739340109 313739340109 313739340109
450 Discharge Pipe-A 9368338008 9368338008 9368338008
527 Protection Net 9352163012 9352163012 9352163012
575 Condensing Pipe-C 9363460001 9363460001 9363460001
620 Inlet Pipe (Cond.) Assy 9353183002 9353183002 9353183002
628 Locking Spacer 313005446558 313005446558 313005446558
646 Compressor Cover-B 9370774047 9370774047 9370774047
653-1 Bolt (Fan Motor Fixing) 9385089020 9385089020 9385089020
678 Bracket (Thermistor) 313557406106 313557406106 313557406106
734 Cabinet Top Plate 9352161018 9352161018 9352161018
735 Distributor Assy 9353187000 9353187000 9353187000
790-1 Belt Heater-A 9361140042 9361140042 9361140042
791 Magnetic Relay 9363277005 9363277005 9363277005
803 Cabinet-D, Painted 9352150012 9352150012 9352150012
805 Blower Cover Corner 9352160011 9352160011 --------
808 Inlet Pipe (Accumulator)-A 9363458008 9363458008 9363458008
809 Ball Valve-A 9357976006 9357976006 9357976006
810 Ball Valve-B 9357982006 9357982006 9357982006
Ord.
Q'ty
Description
Ord.
Q'ty
Part No.
To Next Page
