Fujitsu AUU18RC

305.5
298.5
248.5
200
60 (Drain pipe) 100 (Small pipe) 70 (Large pipe)
33-1/32"(840)
13-1/4"(336)
31-21/32"(804)
25-1/8"(643)
13-7/64"(333)
9-11/16"
(246)
9-1/4"
(235)
9-25/32"
(248.5)
11-3/4"
(298.5)
12
(305.5)
1"(25)
1-3/16"
(30)
37 (940)
37 (940)
2-3/8"(60) (Drain pipe)
Drain inside Dia. ø1-17/64"(ø32)
outside Dia. ø1-29/64"(ø37)
3-15/16"(100) (Small pipe) 2-3/4"(70) (Large pipe)
32-11/16"(830)
32-11/16"(830)
– 2 –
Models : AUU18RC
AUU24RC
Models : AOU18RC
AOU24RC
OUTLINE AND DIMENSIONS
INDOOR UNIT
Unit : inch (mm)
OUTDOOR UNIT
