Fujitsu AUXG07-22KVLA User Manual

Power supply
(50 Hz, 230 V)
Indoor rated
Wiring spec. of connection
cable
(Indoor unit to outdoor
unit)
Type Model name
MCA
Input
power
FLA
Cross-
sectional
area
Limited
wiring
length
(A) (W) (A)
(mm
2
)
(m)
Wall mounted
ASYG07KGTB 0.25 23 0.20
1.5 26
ASYG09KGTB 0.30 27 0.24
ASYG12KGTB 0.30 27 0.24
ASYG14KGTB 0.37 33 0.29
ASYG07KGTE 0.25 23 0.20
ASYG09KGTE 0.30 27 0.24
ASYG12KGTE 0.30 27 0.24
ASYG14KGTE 0.37 33 0.29
ASYG18KMTB 0.44 38 0.35
ASYG22KMTB 0.49 47 0.39
ASYG24KMTB 0.55 62 0.44
ASYG18KMTE 0.44 38 0.35
ASYG22KMTE 0.49 47 0.39
ASYG24KMTE 0.55 62 0.44
ASYG07KMTB 0.25 23 0.20
ASYG09KMTB 0.30 27 0.24
ASYG12KMTB 0.30 27 0.24
ASYG14KMTB 0.38 33 0.30
ASYG07KMCC 0.25 23 0.20
ASYG09KMCC 0.30 27 0.24
ASYG12KMCC 0.30 27 0.24
ASYG14KMCC 0.38 33 0.30
ASYG07KMCE 0.25 23 0.20
ASYG09KMCE 0.30 27 0.24
ASYG12KMCE 0.30 27 0.24
ASYG14KMCE 0.38 33 0.30
ASYG07KETA
ASYG07KETA-B
0.25 23 0.20
ASYG09KETA
ASYG09KETA-B
0.30 27 0.24
ASYG12KETA
ASYG12KETA-B
0.30 27 0.24
ASYG14KETA
ASYG14KETA-B
0.38 33 0.30
ASYG07KETE
ASYG07KETE-B
0.25 23 0.20
ASYG09KETE
ASYG09KETE-B
0.30 27 0.24
ASYG12KETE
ASYG12KETE-B
0.30 27 0.24
ASYG14KETE
ASYG14KETE-B
0.38 33 0.30
- 164 -
9. Electrical characteristics
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT MULTI-SPLIT TYPE

Fujitsu AUXG07-22KVLA Specifications

General

Brand	Fujitsu
Model	AUXG07-22KVLA
Category	Air Conditioner
Language	English
