Fujitsu AUXG07-22KVLA User Manual

2. Dimensions
2-1. Model: AOYG36KBTA5
600
353 330
109
4- M1 0 hole
820
19
99
884
20
20
18
16
315
410
37
Drain port Ø42
Side viewSide view Front view
Top view
Pitch of bolts for installation
Bottom view
Pitch of bolts for installation
Airflow
Unit: mm
Side view (Valve part)
17 71
168
46
92
92 ×4=368
- 434 -
2-1. Model: AOYG36KBTA5 2. Dimensions
OUTDOOR UNIT AOYG36KBTA5 OUTDOOR UNIT AOYG36KBTA5

Fujitsu AUXG07-22KVLA Specifications

General

Brand	Fujitsu
Model	AUXG07-22KVLA
Category	Air Conditioner
Language	English
