Fujitsu AUXG07-22KVLA - Wiring Diagrams

¢ Models: ASYG07KMCE, ASYG09KMCE, ASYG12KMCE, and
ASYG14KMCE
Unit: mm
834
270
222
3.0
(834)
344 356
327 11332767
62
50
62
84
43
(270)
43
Outline of indoor unit
for pipe inlet Ø65 for pipe inlet Ø65
359
418
492
- 49 -
3-5. Wall mounted type 3. Dimensions
4-5 UNIT MULTI-SPLIT TYPE 4-5 UNIT
MULTI-SPLIT TYPE
